Key Features:
Independently developed polymer material diaphragm, loaded with optically active components, solid and durable,
no pretreatment required, fast response speed
, no reagents required, no secondary pollution, economical and environmentally friendly
, built-in temperature compensation algorithm to ensure measurement accuracy, good long-term stability,
built-in plug-and-play full-function digital controller, with calibration record storage function, no calibration required for first use
Product parameters:
Range and resolution: 0～100.00mg/L 0.01mg/L0～1000.0mg/L 0.1mg/L
Accuracy: ±10% or ±1mg/L, ±0.5℃
Working temperature: 0～40℃
Working pressure: <0.1MPa
pH range of medium: 4～10pH
Temperature compensation: Automatic temperature compensation (Pt1000)
Power supply: 12~24VDC
Signal output: RS-485 (Modbus/RTU)
Shell material: PVC and POM
Installation method: 3/4NPT pipe thread, immersion installation
Cable length: 5 meters, other lengths can be customized
Calibration method: two-point calibration
Power consumption: 0.2W@12V
Protection level: IP68
