Key Features:
No reagents required, no pollution, low power consumption, anti-interference design, economical and environmentally friendly;
Small size, more convenient installation, and can monitor water quality online continuously;
Can measure parameters such as COD, turbidity and temperature; automatically compensate for turbidity interference;
Equipped with a cleaning brush to prevent biological adhesion; small drift, fast response, and more accurate measurement;
Even with long-term monitoring, it still has excellent stability; maintenance-free, long service life, and low cost;
Product parameters:
1. Measurement principle: dual wavelength ultraviolet absorption method
2. COD range: 0-100mg/L equiv. KHP
3.COD accuracy: ±5%FS
4.COD resolution: 0.1mg/L
5. Turbidity range: 0-100NTU
6. Turbidity accuracy: ±5%FS
7. Turbidity resolution: 0.1NTU
8. Calibration method: two-point calibration
9. Output mode: RS-485 bus, Modbus/RTU protocol
10. Power supply: 12~24VDC±10%
11. Power consumption: <0.5W
12. Working conditions: 0～45℃, <0.2MPa
13. Storage temperature: -5～65℃
14. Protection grade: IP68
15. Installation method: immersion installation
16. Cable length: 5 meters, other lengths can be customized
17. Sensor housing material: POM and 316L stainless steel
