Features:
No electrolyte required, no polarization, no oxygen consumption, no flow rate impact
Built-in temperature sensor, automatic temperature compensation, built-in salinity compensation, flexible parameter settings
Not affected by chemicals such as sulfide, small drift, fast response, more accurate measurement
Long service life, lower cost, easy replacement of fluorescent film head, simple maintenance
Low power consumption and anti-interference design
Product parameters:
1. Measurement principle: fluorescence method
2. Measuring range: 0～20mg/L (0～200% saturation)
3. Resolution: 0.01mg/L, 0.1℃
4. Accuracy: ±2%FS, ±0.5℃
5. Temperature compensation: automatic temperature compensation (Pt1000)
6. Output mode: RS-485 bus, Modbus-RTU protocol
7. Working conditions: 0～45℃, <0.2MPa
8. Storage temperature: -5～65℃
9. Cable length: 5 meters, other lengths can be customized
10. Power consumption: <0.5W
11. Power supply: 12~24VDC ±10%
12. Protection grade: IP68
13. Calibration method: two-point calibration
14. Fluorescent cap life: guaranteed for one year (under normal use)
15. Sensor housing material: POM and 316L stainless steel
