Product parameters:
Measuring principle: Constant voltage method
Measuring range: 0～2.000mg/L(HClO)
Resolution: 0.001mg/L
Accuracy: ±5% or ±0.05mg/L, ±0.5℃
Calibration function: Two-point calibration
Working pressure: <0.1MPa
pH range of medium: 4～9pH
Temperature compensation: Automatic temperature compensation (Pt1000)
Signal output: RS-485 (Modbus/RTU)
Shell material: POM, PTFE
Working temperature: 5～50℃
Installation method: Flow cell installation
Size: 30×233mm
Flow rate: 30～60L/h
Response time: <30S
Power consumption: 0.2W@12V
Power supply: 12~24VDC
Protection level: IP68
