Key Features:
90° scattered light principle, built-in temperature sensor
Fiber optic structure, strong resistance to external light interference
Infrared LED light source, high stability
IP68 protection, water depth up to 20 meters
Product parameters:
1. Output signal: support RS-485, MODBUS/RTU protocol
2. Measurement method: 90° scattered light method
3. Range: 0~1000NTU or 0~200NTU
4. Accuracy: ±5% of indicated value or ±3NTU, whichever is greater (0～1000NTU); ±3% of indicated value or ±2NTU, whichever is greater (0～200NTU), ±0.5℃
5. Resolution: 0.1NTU, 0.1℃
6. Working conditions: 0～50℃, <0.6MPa
7. Calibration method: two-point calibration
8. Response time: 30 seconds T90
9. Temperature compensation: automatic temperature compensation (Pt1000)
10. Power supply: 12 or 24VDC±10%, 10mA;
11. Dimensions: diameter 30mm; length 166.5mm;
12. Protection level: IP68; water depth 20 meters;
13. Service life: Sensor 3 years or more
14. Cable length: 5 meters (default), customizable
15. Sensor housing material: PVC or titanium alloy (other)
