JD05 Tipping Bucket Rain Gauge

The tipping bucket rain gauge converts rainfall into digital signal output in the form of switch quantity, meeting the needs of information transmission, processing, recording and display. The performance meets the relevant requirements of the national standard GB/T11832-2002 "Tipping bucket rain gauge" and the national standard GB/T11831-2002 "Hydrological measurement and reporting device telemetry rain gauge". It is suitable for meteorological

Send Inquiry User Manual Calibration Certification

Product Details of JD05 Tipping Bucket Rain Gauge

Working principle:

JD05 tipping bucket rain gauge is a primary , and its performance meets the requirements of the national standard GB/T 21978.2-2014 "Requirements for Precipitation Observation".

The core component of this instrument, the tipping bucket, adopts a three-dimensional streamlined design, which makes the tipping bucket turn over water more smoothly, and has the function of self-cleaning dust and easy cleaning.

Technical parameters:

1. Water receiving diameter: Ф200+0.6mm, outer edge angle 45°

2. Resolution: 0.1, 0.2, 0.5 mm Measurement accuracy: ±3% (indoor static test, rainfall intensity is 2 mm/min)

3.Measure precipitation intensity: 0mm/min-8mm/min, 10mm/min can work Resolution: 0.5mm

4. Average effective working hours: ≥50,000

5. Dimensions: diameter × height φ265 × 391mm Weight: 3kg

6. Working temperature: -40℃-60℃

7. Output signal: switch quantity
